The all-in-one solution for bridge waterproofing

The new Wecryl waterproofing system below asphalt |  is a dynamic, highly crack-bridging waterproofing system based on PMMA resins for bridges. This new and innovative system meets the performance requirements of ETAG 033 (EAD) and ZTV-ING, making it the international and national solution for bridge waterproofing with the highest performance characteristics. The optimised properties of the Wecryl 240 waterproofing resin exceed all regulated quality standards.

The waterproofing membrane is designed as a single layer without a fabric insert - the more efficient waterproofing resin leads to optimised consumption. Beyond the requirements of ETAG 033, the higher requirements for crack bridging capacity according to ZTV-ING, Part 6, Section 3 or TL/TP-BEL-B 3 (1995 version and 2012 draft version) are fulfilled.

Furthermore, classes B 4.2 and A5 (-30 °C) according to DIN EN 1062-7 are achieved.

Your advantages

When using the waterproofing system and asphalt

Your advantages

When using the waterproofing system below asphalt

Inspected and tested

According to ETAG 033 (EAD) and ZTV-ING, Part 6,
Section 3

Maximum area output

More than 3,000 m²/day possible due to single-layer, fleece-free liquid waterproofing
(optimised consumption 2.4 kg/m²)

Planning security

Static crack bridging > 8.0 mm (class A5) and dynamic crack bridging
Crack bridging class B 4.2 (-30 °C) according to DIN EN 1062-7.

Long service life

Optimised shear bond strengths between asphalt and liquid sealant

More economical on steel substrates

No primer required on steel substrates

Our promise

Experienced technicians with their own opinions and backbone who focus on every construction site. We are never satisfied with what we have achieved, but state clearly what is possible and what is not. That's why there is no standard with us, but solution-oriented, practical advice, coupled with the strong service of our interdisciplinary team.

WestWood® employs people with ambition and, above all, enthusiasm for progressive ideas, which has long since made us the innovation leader for waterproofing and coating systems made of modern liquid plastics. But also people who take responsibility and have the courage to rethink even the tried and tested. Here, free spirits and forward thinkers are at work.

In all applications, our customers not only appreciate the "Made in Germany" products that we produce in Petershagen. They also know our strong urge to always find the best solution for you using unconventional methods.

CONTACT US NOW

On video: The system

Dennis Weitz, B.A. BWL (FH) | Int. Key-Account-Manager Road, Bridge, Traffic

Innovative
together.

To permanently seal components and building surfaces with a wide variety of geometries
– that is the mission of WestWood®
1999
Founding year
9,000 t
Production capacity
16 countries
already trust WestWood®
8,000 m²
Production area

The structure

of the waterproofing system below asphalt
  • Finished surface
    7 Asphalt
  • Protection and utility level
    6 Wecryl 890 Tack Resin
  • Sealing level
    5 Wecryl 240
  • Priming layer
    4 optional: Wecryl 131 / Wecryl 131 K
  • Priming layer
    3 Wecryl 130
  • Priming layer
    2 optional: Wecryl 821 (substrate stabiliser)
  • Underground
    1 e.g. concrete
  • Finished surface
    7 Asphalt
  • Protection and utility level
    6 Wecryl 890 Tack Resin
  • Sealing level
    5 Wecryl 240
  • Priming layer
    4 optional: Wecryl 131 / Wecryl 131 K
  • Priming layer
    3 Wecryl 130
  • Priming layer
    2 optional: Wecryl 821 (substrate stabiliser)
  • Underground
    1 e.g. concrete

Why Wecryl waterproofing system below asphalt from WestWood® Kunststofftechnik GmbH?

The new "Wecryl waterproofing system below asphalt" combines the components from the proven systems "Wecryl H PMMA sealing system" and "Wecryl waterproofing system below mastic asphalt", thus creating a high-performance system.

Wecryl 130 is the optimal primer when reliability and adhesion properties between the concrete substrate and the liquid plastic waterproofing are required. The waterproofing Wecryl 240 is absolutely low-temperature flexible and highly crack-bridging even at temperatures as low as -30 °C. Not only the bond between the waterproofing and the concrete is important, but also the bond adhesion between the waterproofing and the wearing course. Wecryl 890 Tack resin ensures an absolutely secure bond between the two layers. Also developed on the basis of methyl methacrylate, the complete system structure remains in one binder group and creates unique values as a system in terms of adhesion:

- Adhesive bond to substrate and asphalt -
- Shear strength -
- Crack bridging -

Contact us now

Audited according to:

Convince yourself of our high-quality Wecryl waterproofing system below asphalt and trust our many years of experience to make your project a success.

We will be happy to arrange an appointment with you! We look forward to hearing from you!
